| Model | L 1100 | |||
|---|---|---|---|---|
| 8ΩStereo Power | 4 x 1100W | |||
| 4ΩStereo Power | 4 x1650W | |||
| 2Ω Stereo Power | 4x2200W | |||
| Channels | 4 | |||
| Outputs Connectors | Speakon Connectors | |||
| Frequency Respinse | 20Hz-30KHz+-0.5dB | |||
| Signal Noise Ration(dB) | 110dB | |||
| THD+N(rated power,40/KHz)% | <0.1% | |||
| Input Lmpedance | 20K Ω balanced / 10K Ω unbalanced | |||
| Input Gain | Rear Panel:0.775V/1.0V/1.4V | |||
| Fan | 4PCS temperature control cooling Fan | |||
| Protection | Protection of short circuit,open circuit,overheat,DC,super sonic frequency etc | |||
| Indicators(per Channel) | Protect indicator,signal indicator,work indicator | |||
| Power Requirement | 200-240v~50-60Hz | |||
| Dimensions | 483 x 430 x88mm | |||
| Transport Dimension | 575╳555╳140mm | |||
| Net Weight | 52KG | |||
| Gross Weight | 55KG | |||
