| Model | AOW 1000 | AOW 1400 | AOW1600 | |
|---|---|---|---|---|
| 8ΩStereo Power | 4 x 1000W | 4 x 1400W | 4 x 1600W | |
| 4ΩStereo Power | 4 x 1900W | 4 x2200W | 4 x 2600W | |
| Channels | 4 | |||
| Outputs Connectors | Speakon Connectors | |||
| Frequency Respinse | 20Hz-30KHz+-0.5dB | |||
| Signal Noise Ration(dB) | 110dB | |||
| THD+N(rated power,40/KHz)% | <0.1% | |||
| Input Lmpedance | 20K Ω balanced / 10K Ω unbalanced | |||
| Input Gain | Rear Panel:00dB,-3dB,-6dB,-9dB,-15dB,-18dB,-21dB | |||
| Fan | 4PCS temperature control cooling Fan | |||
| Protection | Protection of short circuit,open circuit,overheat,overload ,DC,super sonic frequency etc | |||
| Indicators(per Channel) | Protect indicator,signal indicator,work indicator | |||
| Power Requirement | 200-240v~50-60Hz | |||
| Dimensions | 530 x 485 x90mm | |||
| Transport Dimension | 575╳555╳140mm | |||
| Net Weight | 26KG | 27KG | 28KG | |
| Gross Weight | 28KG | 29KG | 30KG | |
